USER MANUAL « ASP 116 EVOLUTION »
CONFIGURATION
Sprinte SAS, All rights reserved, including translation rights
53
3 Configuration of electronic boards « inputs / outputs »
I / O boards are fully programmable electronic
CONFIGURATION ► I/O BOARDS
211SP BOARD
Inputs / outputs of 211SP
216SP BOARD
Inputs / outputs of 216SP
217SP 0 BOARD
Inputs / outputs of 217SP (extension 1)
217SP 1 BOARD
Inputs / outputs of 217SP extension 2)
220SP BOARD
Inputs / outputs of 220SP
223SP 0 BOARD
Inputs / outputs of 223SP (extension 1)
223SP 1 BOARD
Inputs / outputs of 223SP (extension 2)
230SP BOARD
Inputs / outputs of 230SP (Bluetooth)
LANDING BUS
BOARDS
Inputs / outputs of 137SP and 228SP landing bus
3.1 Car and floors buttons
3.1.1 216SP
CONFIGURATION ► I/O BOARDS ► 216SP
PE5M, TR2M
Lift buttons connectors
[TYPE] [LEVEL]
[NO CONNECTED] [CAR DOOR1] [CAR DOOR2] [UP FLOOR DOOR1]
[UP FLOOR DOOR2] ] [DOWN FLOOR DOOR1] [DOWN FLOOR DOOR2]
3.1.2 217SP
CONFIGURATION ► I/O BOARDS ► 217SP
To assign the connectors to lift calls the following parameter must be configured:
[CONNECTOR] = [LIFT BUTTONS]
ES1-X, ES2-X
ES3-X, ES4-X
[TYPE] [LEVEL]
[NO CONNECTED] [CAR DOOR1] [CAR DOOR2] [UP FLOOR DOOR1]
[UP FLOOR DOOR2] ] [DOWN FLOOR DOOR1] [DOWN FLOOR DOOR2]
