Presentation
This manual is the reference document for installation and maintenance of your “ASP 116 evolution” control
panel. It explains in detail the configuration and diagnostic of your control panel.
This new range of control panels designed by Sprinte introduces the latest technology to meet lifts’ new
requirements. The “ASP 116 evolution” control panel is modular and particularly suited to modernising lifts.
Main functionalities:
- 32 floors
- CANopen LIFT compliant
Power control options:
- Variable frequency control 4 kw to 55 kw (Gear and Gearless)
- One or two speed control
- Speed until 1.6 m/s
- Optimization of energy consumption
Car positioning
- Magnetic reader with magnets on guide rails
- Optic fork (224SP)
- Absolute encoder with notched band (K04SP)
- Absolute reader with encoded stainless steel band./
Operation type:
- Universal travel, Up or Down Collective, Full Collective
- Up to quadruplex control
- Fire EN 81-73
- Inspection and emergency operation
- Key “reserved car”
- Overload detection
- Access codes with the car operating panel
- Two car operating panel
Door controls
- 2 doors
- Manual doors
- Fully automatic doors
- VVF doors (Nudging)
- Door open levelling
- Two doors with passing or selective mode
- Automatic and manual landing doors on the same face
Indicators
- Positions indicators (Dot matrix, LCD, TFT colour)
- Direction and next departure arrows
- Voice announcement of floor
