USER MANUAL « ASP 116 EVOLUTION »
CONFIGURATION
Sprinte SAS, All rights reserved, including translation rights
15
2.7 Temperature control
SETUP ► TEMPERATURE
Chapter 0.4.16 of the standard EN81-20:2014: To ensure the correct functioning of the equipment in the well
and machinery space(s), i.e. taking into account the heat dissipated by the equipment, the ambient
temperature in the well and the machinery space(s) is assumed to be maintained between +5 °C and +40 °C.
Temperature control in the control panel
This security prohibiting lift operation if the temperature in the control panel exceeds the maximum tolerances
authorised by the electronic components.
MAX PANEL T°
Maximum temperature in control panel
If the temperature exceeds this threshold, the lift makes the passengers exit and
goes out of service until the temperature comes back down below the threshold
[20..70] °C (70°C by default)
MIN PANEL T°
Minimum temperature in control panel
If the temperature goes below this threshold, the lift makes the passengers exit and
goes out of service until the temperature goes back up above the threshold
[-10..15] °C ( 0°C by default)
Temperature control in machine room
Security prohibiting lift operation if the temperature in the machine room exceeds the maximum tolerances
authorised by the standard.
MACHINE ROOM T°
Activation of the temperature controls in the machine room
Le control sis done by a 132SP temperature captor that it is connected to the MC2M
connector of the 216SP board.
[YES]* [NO]
MAX MACHINE T°
Maximum temperature in machine room
If the temperature exceeds this threshold, the lift makes the passengers exit and
goes out of service until the temperature comes back down below the threshold
[20..60] °C (40°C by default)
MIN MACHINE T°
Minimum temperature in machine room
If the temperature exceeds this threshold, the lift makes the passengers exit and
goes out of service until the temperature comes back down below the threshold
[-10..15] °C ( 0°C by default
)
HEATING
Switching on heating if temperature is lower than the threshold
Output CN6I-CHAUF / 220SP is activated
[-10..18] °C ( 5°C by default)
VENTILATION
Switching on ventilation if temperature is greater than threshold
Output CN6I-VENT / 220SP is activated
[22..60] °C ( 30°C by default)
