USER MANUAL « ASP 116 EVOLUTION »
Sprinte SAS, All rights reserved, including translation rights
Connection of automatic car light 230V (managed
by timer)
Connection of continuous car light 230V
Connection of automatic car light 230V (managed
by timer)
Connection of continuous car light 230V
Connection of top inspection end limit
Connection of bottom inspection end limit
Connection of top and bottom inspection end limit
Connection of folded out balustrade
Connection of safety gear
Connection of inspection box (Inspection safety +
plug car roof)
Connection of folded up balustrade
Connection of automatic or manual toe-guard
Connection of inspection box (Inspection safety)
Connection of rocker detection 1 m for automatic
toe-guard + contact toe-guard status
Cell connection by 24Vdc or 230Vac (DOOR2)
Connection of 2
nd
service stop
Connection of car trap-door
Cell connection by 24Vdc or 230Vac (DOOR1)
Connection door 1 motor power supply + door safety
Additional 230V power supply (Power supply
provided by transfo in control panel)
Connection of safety relay (levelling door open)
Connection telephone line on telephone
Connection cam 1 (power supply configurable in
control panel)
Connector connecting trailing cable to 210SP to
212SP boards (Levelling safety)
Connector connecting trailing cable to 210SP to
212SP boards (telephone line)
Connector connecting trailing cable to 210SP to
212SP boards (main safety chain)
Connector connecting trailing cable to terminals in
control panel (Power supply 220F + Power supply
motor)
Connector connecting trailing cable to terminals
in control panel (Power supply cam 1)
Connector connecting 210SP board to the 221SP
board (reduced stand-by + pit inspection option)
Connector connecting 211SP board to 210SP
board
Connector connecting 210SP board to the 221SP
board (reduced stand-by + pit inspection option)
Connector connecting 210SP board to 222SP
board (Option 2
nd
door service)
Continuous 230V power supply (Car lighting)
