Sun Microsystems SPARCstation 5 - System Board Layout; Replaceable System Board Components

System Board Overview 10-3
10
10.3 System Board Layout
Figure 10-1 shows the major components on the system board.
Figure 10-1 SPARCstation 5 System Board
10.4 Replaceable System Board Components
The following system board components are replaceable:
• DSIMMs
• S24 card
• SBus cards
• NVRAM
• System board
Chapter 11, “System Board and Component Replacement,” describes how
to remove and replace these components.
SBus slots
DSIMMs
PROM
NVRAM
Speaker/LED
connector
Power connector
Diskette drive
SCSI connector
connector
CD-ROM audio
connector
AFX Bus slot
