System Board and Component Replacement 11-25
11
11.5.2 Replacing the NVRAM Chip
1. Locate the NVRAM chip on the system board.
See Figure 11-24.
2. Carefully align the pins and insert the NVRAM chip into the socket;
make certain that the notches on the socket and chip are aligned properly.
The carrier is keyed so that the NVRAM can be installed only one way.
3. Push the NVRAM chip into the carrier until it sits tightly in the socket.
4. Reinstall the SBus card in the center SBus slot (if applicable).
See Section 11.1.2, “Replacing an SBus Card.
5. Detach the wrist strap and replace the cover.
See Chapter 7, “Internal Access.”
6. Power on the system.
See Section 6.2, “Powering On the System.”
