1.1.3 Rear View
Figure 1-3 shows the rear view of the system.
Figure 1-3 Rear View of SPARCstation 5 System
Legend:
1—AC On/Standby switch 7—SCSI 13—Keyboard
2—AC power outlet 8—Parallel 14—Audio, headphone
3—Lock block 9—AUI Ethernet 15—Audio, line-out
4—SBus 10—Twisted-pair Ethernet 16—Audio, line-in
5—SBus or AFX Bus 11—Serial port B 17—Audio, microphone
6—AC power receptacle 12—Serial port A
23 41
13121110915
14
687
16
17
5
