Table B.1.15. Header of the Summary Results Record (saved in Summary Results Record)
Word
number
Name
Comment
0
0xnn59
[59, nn=header’s length]
1..2
RecNumber
Summary Results Record number: 1..
…
…
…
Table B.1.16_SLM. Main results in the SLM mode (saved in Summary Results Record)
Word
number
Name
Comment
0
0xnn07
[07, nn=block’s length]
1
0x0307
[used_profile, profile’s mask]
2
0xmm08
[08, mm=sub-block’s length]
3..4
MeasureTime
time of the measurement
5
Result[1][1]
Lxpeak
1
value in the 1
st
profile (*100 dB)
6
Result[1][2]
LxyE
23
value in the 1
st
profile (*100 dB)
7
Result[1][3]
maximal value (Lxymax
2
) in the 1
st
profile (*100 dB)
8
Result[1][4]
minimal value (Lxymin
2
) in the 1
st
profile (*100 dB)
9
Result[1][5]
Lxy
2
value in the 1
st
profile (*100 dB)
10
Result[1][6]
Lxyeq
23
value in the 1
st
profile (*100 dB)
11
Result[1][7]
Lden value in the 1
st
profile (*100 dB)
12
Result[1][8]
Ltm3 value in the 1
st
profile (*100 dB)
13
Result[1][9]
Ltm5 value in the 1
st
profile (*100 dB)
14
Result[1][10]
LR1 value in the 1
st
profile (*100 dB)
15
Result[1][11]
LR2 value in the 1
st
profile (*100 dB)
16
UnderRes[1]
under-range value in the 1
st
profile
17..18
ULTime[1]
reserved
19..20
PTC[1]
reserved
21
UnitFlags
flags word for measurement cycle (definition in table B.1.6)
22
EX[1]
EX (Expected Value) in the 1
st
profile (*100 dB)
23
SD[1]
SD (Standard Deviation) in the 1
st
profile (*100 dB)
24
0xmm08
[08, mm=sub-block’s length]
25..26
OVL
overload time
27
Result[2][1]
Lxpeak
1
value in the 2
nd
profile (*100 dB)
28
Result[2][2]
LxyE
23
value in the 2
nd
profile (*100 dB)
29
Result[2][3]
maximal value (Lxymax
2
) in the 2
nd
profile (*100 dB)
30
Result[2][4]
minimal value (Lxymin
2
) in the 2
nd
profile (*100 dB)
31
Result[2][5]
Lxy
2
value in the 2
nd
profile (*100 dB)
