Svantek SV 971A User Manual

SV 971A User Manual – Appendixes
193
32
Result[2][6]
Lxyeq
23
value in the 2
nd
profile (*100 dB)
33
Result[2][7]
Lden value in the 2
nd
profile (*100 dB)
34
Result[2][8]
Ltm3 value in the 2
nd
profile (*100 dB)
35
Result[2][9]
Ltm5 value in the 2
nd
profile (*100 dB)
36
Result[2][10]
LR1 value in the 2
nd
profile (*100 dB)
37
Result[2][11]
LR2 value in the 2
nd
profile (*100 dB)
38
UnderRes[2]
under-range value in the 2
nd
profile
39..40
ULTime[2]
reserved
41..42
PTC[2]
reserved
43
UnitFlags
flags word for measurement cycle (definition in table B.1.6)
44
EX[2]
EX (Expected Value) in the 2
nd
profile (*100 dB)
45
SD[2]
SD (Standard Deviation) in the 2
nd
profile (*100 dB)
46
0xmm08
[08, mm=sub-block’s length]
47..48
Reserved
reserved
49
Result[3][1]
Lxpeak
1
value in the 3
rd
profile (*100 dB)
50
Result[3][2]
LxyE
23
value in the 3
rd
profile (*100 dB)
51
Result[3][3]
maximal value (Lxymax
2
) in the 3
rd
profile (*100 dB)
52
Result[3][4]
minimal value (Lxymin
2
) in the 3
rd
profile (*100 dB)
53
Result[3][5]
Lxy
2
value in the 3
rd
profile (*100 dB)
54
Result[3][6]
Lxyeq
23
value in the 3
rd
profile (*100 dB)
55
Result[3][7]
Lden value in the 3
rd
profile (*100 dB)
56
Result[3][8]
Ltm3 value in the 3
rd
profile (*100 dB)
57
Result[3][9]
Ltm5 value in the 3
rd
profile (*100 dB)
58
Result[3][10]
LR1 value in the 2
nd
profile (*100 dB)
59
Result[3][11]
LR2 value in the 2
nd
profile (*100 dB)
60
UnderRes[3]
under-range value in the 3
rd
profile
61..62
ULTime[3]
reserved
63..64
PTC[3]
reserved
65
UnitFlags
flags word for measurement cycle (definition in table B.1.6)
66
EX[3]
EX (Expected Value) in the 3
rd
profile (*100 dB)
67
SD[3]
SD (Standard Deviation) in the 3
rd
profile (*100 dB)
…
…
…
1
x - depends of the filter type for Peak result calculation in selected profile: A, C, Z, B (cf.
Tab. B.1.10)
2
x - depends of the filter type in selected profile: A, C, Z, B (cf. Tab. B.1.10)
y - depends of the detector type in selected profile: I (imp.), F (fast), S (slow) (cf. Tab. B.1.10)
3
y - only for exponential detector's type (cf. Tab. B.1.6)
