9. Transmission
9-1
Mechanism Diagram ··························· 9-1
Precautions in operation ···················· 9-2
Trouble Diagnosis ······························· 9-2
Transmission Disassembly ················ 9-3
Transmission Inspection··················· 9-7
Bearing Replacement ························ 9-9
Transmission Reassembly················ 9-12
Mechanism Diagram
Final shaft
Reverse Shaft
Drive shaft
Home page
Contents
Shift fork
Shift Drum
Counter Shaft
Left crank case
Radial Ball Bearing 6307
Bevel Gear Housing
Needle Bearing HK2220C
Radial Ball Bearing 6228
Radial Ball Bearing 6304
Needle Bearing HK2220C
Drive Bevel Gear
Slidin
Claw
Counter Gear
Park Gear
9
