11. A.C. GENERATOR/ST
Mechanism Diagram··························· 11-1
Precautions in Operation··················· 11-2
Right Crankcase Cover Removal ······ 11-3
A.C. Generator Removal····················· 11-3
Flywheel Removal······························· 11-4
Starter One-way Clutch Removal ······ 11-4
Recoil Starter Cover Removal ··········· 11-5
Starter One-way Clutch Installation ·· 11-6
Flywheel Installation··························· 11-7
A.C. Generator Installation················· 11-8
Right Crankcase Cover Installation··· 11-8
Mechanism Diagram
Recoil Starter Grip
11-1
Recoil Starter Cover
Volute Spring
Starter Drive Pulley
11
R. Case Cover
Stator Rope
Stator Ratchet Water Pump Shaft
Recoil Stator Cover Gasket
Stator Driven Pulley
Starter One Way Clutch
Flywheel
Stator
Starting Clutch Gear
R. Cover Gasket
To Next Page
