11. A.C. GENERATOR/STARTING CLUTCH
11-5
Check each roller for wear or damage.
Recoil Starter Cover Removal
Loosen bolt on the ratchet cover then remove
ratchet cover.
Remove the starter ratchets from the ratchet
cover.
Remove the 2 springs from the ratchet cover.
Starter ratchet
2 springs
