13. COOLING SYSTEM
13-6
Check reserve tank
Remove the front center cover, and then
remove reserve tank filler cap.
Check the liquid level in the front fender right
side. Add coolant to proper level if too low.
Reinstall the reserve tank filler cap.
Caution
Do not add too much coolant to prevent the
coolant backflow flooding when the temperature
rises.
Radiator
Check
Remove the front center cover, side covers and
front fender.
(Refer to chapter 13), check for any
leakage from weld seam.
Blow the radiator fins with compressed air. If the
radiator is blocked by dirt, use low-pressured
water jet to clean it.
Be careful straightening the radiator fins.
Removal
Remove the radiator outlet hose to drain out the
coolant.
Remove the radiator hose clamp and hose.
Upper
Radiator hose
To this chapter contents
Lower
Clamp
Radiator outlet hose
Clamp
