16. STEERING / FRONT SUSPENSION
16-9
Knuckle Assembly
Assemble bearing 6006uu by special tool.
Assemble bearing 6006uu by special tool in the
knuckle then lock the nut.
Install the bearing with special tool & air tool.
Tools number: SYM-5024000- REA A6006
Tools name: wheel knuckle body bearing 6006
in puller with air.
Install the cir clip in 55 into knuckle body.
SYM-5024000- REA A6006
SYM-5024000- REA A6006
Nut
SYM-5024000- REA A6006
Air tool
SYM-5024000- REA A6006
