Sym Quad Lander 600 - Home Page 12. Crankcase; Crankshaft

12. CRANKCASE / CRANKSHAFT
12-1
Mechanism Diagram ··························12-1
General Information ···························12-2
Trouble Diagnosis······························12-2
Crankcase Disassembly···················· 12-3
Crankshaft Inspection ······················· 12-5
Crankcase Assembly························· 12-6
Mechanism Diagram
Eng. Oil drain bolt
3.5~4.5kgf-m
12
Home page
Contents
1.0~1.4kgf-m
