4. FUEL SYSTEM
4-4
Carburetor Removal / Installation
Removal
Remove the fuel tank.
Turn the fuel valve lever on off.
Remove 1 screw from throttle lever cap them
remove throttle lever cap.
Loosen throttle cable adjustment nut and remove
throttle cable
Remove the sleep adjustment wire.
Disconnect the fuel hose and by-starter and drain
tube
Release 2 clamps strip of air cleaner and inner
pipe.
Remove the carburetor.
Installation
Install in reverse order of removal procedures.
To this chapter contents
throttle cable
adjustment wire
By-starter
Drain tube
Fuel hose
2 clamps
1 screw
adjustment nut
