3. LUBRICATION SYSTEM
3-5
Oil Filter Unit
Remove the oil filter unit with special tool.
Special Service Tool:
Tool No: SYM-1445100
Install the oil filter unit by hand.
Lock the oil filter unit with special tool.
Special Service Tool:
Tool No: SYM-1445100
Torque value：1.3~1.7kgf-m
Drain bolt
