14. BODY COVER
14-4
Front Fender
Removal
Remove the seat.
Remove the maintenance cover and front top
cover.
Remove the fuel tank cap and fuel tank cover.
Remove the right and left side covers.
Remove 4 screws from footrest.
Remove 4 screws from the right and left inner
protectors.
Remove the inner protectors.
Disconnect the hazard control unit, shift gear
control unit, electricity relay and winker relay on
the front fender.
Remove the front fender.
Installation
Install in the reverse order of removal procedures.
4 bolts
4 screws
4 screws
3 screws
