7. CYLINDER/PISTON
Mechanism Diagram ···························· 7-1 Piston Ring Installation ··················· 7-6
Piston Installation ···························· 7-7
Cylinder Installation························· 7-7
Precautions in Operation ···················· 7-2
Trouble Diagnosis································ 7-2
Cylinder and Piston Removal ············· 7-3
Mechanism Diagram
1.0~1.4kgf-m
7
0.8~1.2kgf-m
7-1
