17. REAR BRAKE & REAR WHEEL & REAR CUSHION
17-9
Rear Cushion
Removal
Remove the rear wheels.
Remove the rear wheel connecter.
Loosen 2 bolts from the rear cushion.
Remove the rear cushion.
Installation
Install rear cushion, and install rear cushion upper
bolt.
Install rear cushion under bolt, and install nut.
Tighten the rear cushion upper bolt and under nut
to the specified torque value.
Torque: 4.6kgf-m
