Sym Quad Lander 600 - Page 119

9. TRANSMISSION
9-10
Install the park gear cir-clip by using cir-clip
installer.
Special tool:
Tool number：SYM-9060200-REA
Tool name：Park gear cir-clip installer
Right crankcase side
Remove the final shaft bearing on the right
crankcase with inner bearing puller.
Special tool:
Tool number：SYM-6204025
Tool name：Inner bearing puller
Remove the counter shaft bearing on the right
crankcase with inner bearing puller.
Special tool:
Tool number：SYM-6204025
Tool name：Inner bearing puller
Remove the drive shaft needle bearing on the right
crankcase with inner bearing puller.
Special tool:
Tool number：SYM-6204025
Tool name：Inner bearing puller
Park
g
ear
Park gear cir-clip installer
To this chapter contents
Inner bearing puller
Cir clip
Cir-cli
p
Inner bearing puller
