10. WHEEL DRIVE SHAFT/PROPELLER SHAFT
10-15
Remove the rear side exit cir-clip.
Remove propeller shaft and rubber boots.
Drive shaft inspection
Check if the spur gear has is damaged or not.
Please replace new parts if it has split or
damaged.
Check if the propeller shaft is split or damaged.
Please replace new parts if it is split or damaged.
Ci
-clip
Rubbe
boot
Spur gea
Propeller shaft
