12. CRANKCASE / CRANKSHAFT
12-7
Install the transmission mechanism to the left
crankcase.
Install the dowel pins and new crankcase gasket.
Install the right crankcase to the left crankcase.
Tighten 13 bolts on the right crankcase.
Tighten 2 bolts on the left crankcase.
Torque value: 0.8~1.2kgf-m
Install the tensioner and tighten the pivot bolt.
Torque value: 0.8 ~1.2kgf-m
Install the cam chain.
Install the cam chain setting plate.
