13. COOLING SYSTEM
13-11
Mount the water pump shaft to the right crankcase
cover.
Install the seal washer into the impeller.
Caution
Washer must be replaced together with the
mechanical seal.
Install the impeller onto the water pump shaft and
tighten.
Torque Value: 1.0~1.4kgf-m
Caution
The impeller is left thread.
Water pump shaft
