3. LUBRICATION SYSTEM
3-8
Tighten the oil pump screw.
Oil Pump Installation
Install the oil pump, and then tighten screws.
Torque value：0.1~0.3kgf-m
Make sure that oil pump shaft can be rotated
freely.
Install the oil pump sprocket, and then install cir
clip onto oil pump shaft.
1 screw
Roller
3 screws
Cir Clip
