User futerface
2212
Service Manual
Product Description
This subsection begins with a general description
of
the traits
of
the 2212
oscilloscope. Three subsections follow, one
for
each of the three classes of
characteristics: nominal traits, warranted characteristics, and typical charac-
teristics.
This oscilloscope uses the front-panel buttons
and
knobs to control its many
functions. The front-panel controls are grouped according to function:
vertical, horizontal, trigger, cursor, setup, and storage. The controls just to the
right of the crt screen are called the display group. Within each group, the
functions are set directly by their
own
front-panel knob.
When Option 10
(GPIB)
and/or Option 12 (RS-232-C) are included most
functions of the oscilloscope can be operated externally
by
a controller
(PC).
Indicators
Several on-screen readouts help you keep track of the settings for various
functions, such as vertical and horizontal scale
and
trigger level. There are
also crt readouts to display the results of measurements, using cursors.
