Mask testing setups Mask types and standards
Learn more a bout mask alignment. (see page 217)
Go to the Mask Setup control window. (see page 209)
Mask types and standards
The following tables list the Mask Types and Standards available with Mask Testing. The standards
available for your instrument depend on the bandwidth and c onfiguration of your instrument.
The Comm Trigger is designed to w ork with communications mask and standard testing. Mask testing
automatically uses Communication triggers. You must install the Serial Communications Mask Testing
Option (see page 209) on some instruments before you can access the Comm triggers.
ITU-T m asks
None
32 Mb 32.064 Mb/s 97 Mb 97.728 Mb/s DS1 Rate 1.544 Mb/s
DS2 Rate Sym 6.312 Mb/s DS2 Rate Coax 6.312 Mb/s DS3 Rate 44.736 Mb/s E1 Sym Pair 2.048 Mb/s
E1 Coax Pair 2.048 Mb/s E2 8.448 Mb/s E3 34.368 Mb/s E4 Binary 0 139.26 Mb/s
E4 Binary 1 139.26 Mb/s STM1E Binary 0
155.52 Mb/s
STM1E Binary 1
155.52 Mb/s
ANSI T1.102 masks
None
DS1 1.544 Mb/s DS1A 2.048 Mb/s DS1C 3.152 Mb/s
DS2 6.312 Mb/s DS3 44.736 Mb/s DS4NA 139.26 Mb/s DS4NA Max Output
139.26 Mb/s
STS-1 Pulse 51.84 Mb/s STS-1 Eye 51.84 Mb/s STS-3 155.52 Mb/s STS-3 Max Output
155.52 Mb/s
Ethernet m asks
None
100Base-TX STP 125 Mb/s 100Base-TX UTP 125 Mb/s Gigabit Ethernet 1.25 Gb/s
1000B-CX Norm, TP2
1.25 Gb/s
1000B-CX Abs, TP2
1.25 Gb/s
1000B-CX Abs, TP 3
1.25 Gb/s
XAUI, Near 3.125 Gb/s
XAUI, Far 3.125 Gb/s 1000B-SX/LX 1.25 Gb/s
SONET/SDH masks
None
OC1/STM0 51.84 Mb/s OC3/STM1 155.52 Mb/s OC12/STM4 622.08 Mb/s
OC48/STM16 2.4883 G b /s OC48-FEC 2.666 Gb/s
Fibre channel masks
None
FC133 Optical 132.8 Mb/s FC266 Optical 265.6 Mb/s FC531 Optical 531.2 Mb/s
FC1063 Optical
1.0625 Gb/s
FC1063 Optical Draft Rev
11
FC2125 Optical 2.125 Gb/s
Fibre channel electrical masks
None
FC133E Elec. 132.8 Mb/s FC266E Elec. 265.6 Mb/s FC531E Elec. 531.2 Mb/s
FC1063E Elec.
1.0625 Gb/s
FC1063E Norm, Beta,
Transm
FC1063E Norm, Delta,
Transm
FC1063E Norm, Gamma,
Transm
FC1063E Abs, Beta,
Transm
FC1063E Abs, Delta,
Transm
FC1063E Abs, Gamma,
Transm
FC1063E Abs, Beta, Recv
