3. Use the multipurpose knob to change the vertical position of the waveform on the screen. Dragging
the waveform handle also positions the waveform.
4. Use the Horizontal knobs to scale and position the waveform on the screen and to set the record length.
Dragging the reference icon also positions the waveform.
5. Use the Resolution knob to set the record length and sample interval.
Set up a bus
NOTE. Use of serial buses may require an option on your instrument.
You can set up parallel or serial buses. For both types of buses, follow theses steps:
1. From the D
igital or the Vertical menu, select Bus Setup.
2. Select the Select tab, scroll through the Bus list, and select the Bus <B1-B16> to configure.
3. To toggle the display of the bus on or off, click the Bus <B1-B16> button.
4. To change the default label of the bus, click the Label box, and use the keyboard to enter a new label.
5. To change the position of the bus in the display, click the Bus Position box, and use the keyboard or
multipurpose knob to adjust the bus position.
6. Continue to set up specific parameters:
for a parallel bus
(see page 580)
for a
n SPI Serial Bus
(see page 582)
for an I2C bus (see page 582)
for a USB bus (see page 584)
for an RS-232 bus (see page 583)
for a MIPI CSI2 Serial Bus (see page 585)
for a MIPI DSI1 Serial Bus (see page 584)
f
or an 8B10B Serial Bus
(see page 111)
Set up a parallel bus
First, follow the common steps to set up any bus (see page 580). To continue to set up a parallel bus,
follow these steps:
580 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
