Tektronix DPO70000C/DX Series User Manual

How to ? Create a math waveform with the Equation E ditor
Create a math waveform with the Equation Editor
Use the following steps to create math waveforms using the Equation Editor:
1. Open the Math Setup control window by clicking Math on the toolbar, or by selecting Math Setup in
the Math menu.
2. In the Math Setup control window, click the Editor button to open the Math Equation Editor.
3. Select a Math waveform from the drop-down list.
4. Select a math function by clicking a button under the tabs on the left side of the Equation Editor (for
example, click Derivative).
5. Select a valid waveform to use as an operand from the Channels Selector
(see page 258).
6. Use other
buttons in the Equation Editor as necessary to create the math expression for the math
waveform.
7. Click OK
to create and display the math waveform.
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 611
