Measurement setups Set up histogram measurements
When you click Cursor, measurements are taken within the boundaries of the vertical cursors. Use the
multipurpose knobs to move the cursors.
When you use vertical cursors to control the gating, you can also specify the cursor mode
(see page 82).
Use the independent cursor mode to move the cursors one at a time with the multipurpose knobs. Use
the tracking
mode to have the cursors track one another; moving Cursor 1 automatically moves Cursor
2intandem.
TIP. Click, hold, and drag across the part of the graticule that you want to measure. After you define the
measurement area, select Measurement Gating from the shortcut menu to place gating cursors around
the measurement area.
Use the sa
me click, hold, and drag method to turn measurement gating off; just select Measurement
Gating Off in the shortcut menu.
What do y
ou want to do next?
Return to the Measurement Setup control window overview. (see page 268)
Learn more about using vertical bar cursors. (see page 79)
Learn more about the Measurement controls. (see page 285)
Learn about setting the Reference Level controls. (see page 286)
Learn about using Measurement Statistics. (see page 285)
Set u
p histogram measurements
Fro
m the Measure menu, select Measurement Setup; then open the Histog tab.
To use
Use this control window to set up the instrument for taking histogram measurements.
F
or information on the controls, click the buttons.
