Analyzing waveforms Export a mark table

To use

Click the Digits button to toggle the display notation between engineering or high precision form.

Export a mark table

From the Analyze menu, select Search

; then open the Results tab.

Overview

Use these controls to export the Mark Table to a ﬁ le.

To use

Export. Click this button to open the Save Marks Table dialog box and export the table to a ﬁle

in CSV format.

View mark counts

From the Analyze menu, select Search; then open the Results tab.
