Tektronix DPO70000C/DX Series User Manual

Trigger setups Set up a Timeout trigger
Overview
Use the controls in this window to set up the Timeout trigger parameters.
To use
For information o n the controls, click the buttons.
NOTE. The Trigger Timeout screen on DPO/DSA Series instrument is same as that on an MSO/DPO5000
and MSO7000
0C Series instrument except for the source selection and Trigger if Timeout Qualification
options.
In some ins
truments, the source selection is a drop-down list and the Trigger if Timeout Qualification
option has Occurs and Logic.
In other i
nstruments the source selection includes a combo list and a Select button. The Trigger if Timeout
Qualification option has Occurs, Logic, and Occurs And.
The fol
lowing Trigger Timeout screen appears on MSO70000C Series instrument:
The following Trigger Timeout screen appears on MSO/DPO5000 Series instruments:
NOTE. TheLogicqualification is not available on DPO5000 and .MSO5000 Series instruments.
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 437
