Oscilloscope Reference High reference

High reference

The High Reference deﬁnes the high reference level of a waveform; the default level is 90%. This

reference level is used with the Low Reference level in the calculation of rise and fall times. To change

this level, c

lick the control, and then set the level with the multipurpose knob.

Histogram box limits - horizontal

Select a mode:

Specify the adjustment:

3. Enter limits:

xxx

826 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
