Oscilloscope Reference Histogram box location - vertical

Histogram box location - vertical

Select a mode:

Specify the adjustment:

3. Enter limits:

xxx

Histogram Max

Displays the voltage of the highest nonzero bin in vertical histograms or the time of the right-most nonzero

bin in the horizontal histograms.

Histogram Mean

Measures the average of all acquired points within or on the histogram box.

Histogram Min

Displays the voltage of the lowest nonzero bin in vertical histograms or the time of the left-most nonzero

bin in the horizontal histograms.

DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 829
