Oscilloscope Reference VXI Plu g-and-Play instrument driver

VXI Plug-and-Play instrument driver

The VXIplug&play instrument driver is a collection of software components, organized according

to the standard VXIplug&play model established by the VXIplug&play Systems Alliance. Use this

VXIplug&pla

y instrument driver to simplify programming tasks when using the following software

development environments:

LabWindows

/CVI

LabVIEW

MATLAB

Visual C++ 6.0

Visual Basic 6.0

HP-VEE
