6 Using the product
0970 4020 en 01 103
6.5.1.6. Erasing text
You also delete a marked area from the diagram with
the
Erase text command.
1. Click on the text that is to be erased.
- The text field is marked.
2. Click on Edit | Tools | Erase text.
- The text field is deleted.
Pos: 139 /TD/Produ kt verwenden/testo Sa veris/05a-2 Kur veneigenschaften/00 Kur veneigenschaften @ 0\ mod_1188996704171_79. doc @ 3636
6.5.1.7. Characteristics of a curve
You can adapt the representation of a measurement series to
your requirements. For example, you can change the line
weight of a curve or the representation of the limit values in the
diagram.
1. Change to the diagram view of the measurement series, the
characteristics of which are to be displayed.
2. Click in the Edit | Curves menu on the entry of the curve,
the characteristics of which are to be displayed.
- The
Characteristics of (name of curve) dialogue is
opened.
The following tabs are available in the dialogue:
•
Curve tab
•
Range limits tab
•
Data sequence tab
•
Statistical computation tab.
Buttons of the dialogue
Button Explanation
[OK] Applies the changed settings. The
dialogue is closed.
[Cancel] Closes the dialogue without applying the
changes.
