7 Maintaining the product
0970 4020 en 01 149
7.5.4. Saveris Ethernet probes
The technical data listed in the following table are valid for all
Saveris Ethernet probes. Special data for the individual probe
types can be found in the following sections.
Characteristic Values
Housing dimensions
(W x H x D)
85 x 100 x 38 mm
Power supply
6.3 V DC mains unit;
alternatively via 24 V AC/DC plug-
in/screw terminals
Buffer battery Li-ion
Housing material Plastic
Protection class IP54
Meas. cycle 2 sec - 24 h
Operating
temperature
-20 to +70 °C
Storage
temperature
-40 to +85 °C
Display (optional) 2-line LCD; 7 segments with symbols
Wall bracket included
