7.5.2. Saveris radio probe
General
The technical data listed in the following table are valid for all
Saveris radio probes. Special data for the individual probe types
can be found in the following sections.
Characteristic Values
Housing dimensions
(W x H x D)
80 x 85 x 38 mm
Length of antenna 81 mm
Weight approx. 240 g
Battery type 4 AA mignon batteries
Battery life
3 years at +25 °C
3 years with Energyzer L91 Photo lithium
batteries for freezer applications
Housing material Plastic
Radio frequency 868 MHz/2.4 GHz
Meas. cycle
Standard 15 min (can be set from 1 min
up to 24 h)
Storage
temperature
-40 to +55 °C
Display (optional) 2-line LCD; 7 segments with symbols
Transmission
distance
approx. 300 m free field at 868 MHz,
approx. 100 m free field at 2.4 GHz
Wall bracket included
