TESTO Saveris - Saveris Converter

4 Product description
0970 4020 en 01 27
Pos: 39 /TD/Produk tbeschreibung/ Übersicht/testo Saver is/04 Converter/ 01 Converter @ 1\mod_119755 7086312_79.doc @ 6416
4.6. Saveris converter
Antenna for receiving the measurement data.
LED for status display.
Connect button for connecting the converter to the Saveris
base and for a status request during operation.
Catch for the wall bracket.
Guide rails for the wall bracket.
Input for external 24 V AC/DC power supply.
Input for connecting the network cable.
Input for service interface.
Input for power supply via mains unit.
Pos: 40 /TD/--- Seitenwechsel --- @ 0\mod_1173774430601_0.doc @ 283
1
2
3
7
8
9
4
5
6
