4.5. Saveris router
Antenna for the radio transmission of the measurement data
LED for status display
Connect button for connecting the router to the Saveris base
and for a status request during operation
Catch for the wall bracket
Guide rails for the wall bracket
Input for external 24 V AC/DC power supply.
Input for service interface
Input for power supply via mains unit
1
2
3
7
8
4
5
6
