T1CC0

T1CC0 T1CC0T1CCn T1CCn

0000h

0-SetOutputonCompare

1-ClearOutputonCompare

4-ClearOutputonCompare-Up,

Seton0

5-ClearWhen T1CC0,SetWhen T1CCn

6-SetWhen T1CC0,ClearWhen T1CCn

2- ToggleOutputonCompare

3-SetOutputonCompare-Up,

Clearon0

T0312-01

www.ti.com

Output Compare Mode

Figure 9-5. Output Compare Modes, Timer Modulo Mode

113

SWRU191C–April 2009–Revised January 2012 Timer 1 (16-Bit Timer)

Submit Documentation Feedback
