Timer 3 and Timer 4 Registers
www.ti.com
T3CCTL1 (0xCE) – Timer 3 Channel 1 Capture/Compare Control
Bit Name Reset R/W Description
7 – 0 R0 Reserved
6
IM
1 R/W Channel 1 interrupt mask
0: Interrupt is disabled.
1: Interrupt is enabled.
5:3
CMP[2:0]
000 R/W Channel 1 compare output-mode select. Specified action on output when timer value equals
compare value in T3CC1
000: Set output on compare
001: Clear output on compare
010: Toggle output on compare
011: Set on compare-up, clear on compare-down in up-down mode. Otherwise, set output on
compare, clear on 0.
100: Clear output on compare-up, set on compare-down in up-down mode. Otherwise clear
output on compare, set on 0.
101: Set output on compare, clear on 0xFF
110: Clear output on compare, set on 0x00
111: Initialize output pin. CMP[2:0] is not changed
2
MODE
0 R/W Mode. Select Timer 3 channel 1 mode
0: Capture mode
1: Compare mode
1:0
CAP[1:0]
00 R/W Capture mode select
00: No capture
01: Capture on rising edge
10: Capture on falling edge
11: Capture on both edges
T3CC1 (0xCF) – Timer 3 Channel 1 Capture/Compare Value
Bit Name Reset R/W Description
7:0
VAL[7:0]
0x00 R/W Timer 3 capture/compare value, channel 1. Writing to this register when T3CCTL1.MODE = 1
(compare mode) causes the T3CC1.VAL[7:0] update to the written value to be delayed until
T3CNT.CNT[7:0] = 0x00.
T4CNT (0xEA) – Timer 4 Counter
Bit Name Reset R/W Description
7:0
CNT[7:0]
0x00 R Timer count byte. Contains the current value of the 8-bit counter
130
Timer 3 and Timer 4 (8-Bit Timers) SWRU191C– April 2009–Revised January 2012
Submit Documentation Feedback
Copyright © 2009–2012, Texas Instruments Incorporated
