I/O Registers
www.ti.com
OBSSEL4 (0x6247) – Observation Output Control Register 4
Bit Name Reset R/W Description
7
EN
0 R/W Bit controlling observation output 4 on P1[4].
0 – Observation output disabled
1 – Observation output enabled
Note: If enabled, this overwrites the standard GPIO behavior of P1.4.
6:0
SEL[6:0]
000 0000 R/W Select output signal on observation output 4
111 1011 (123): rfc_obs_sig0
111 1100 (124): rfc_obs_sig1
11 11101 (125): rfc_obs_sig2
Others: Reserved
OBSSEL5 (0x6248) – Observation Output Control Register 5
Bit Name Reset R/W Description
7
EN
0 R/W Bit controlling the observation output 5 on P1[5].
0 – Observation output disabled
1 – Observation output enabled
Note: If enabled, this overwrites the standard GPIO behavior of P1.5.
6:0
SEL[6:0]
000 0000 R/W Select output signal on observation output 5
111 1011 (123): rfc_obs_sig0
111 1100 (124): rfc_obs_sig1
111 1101 (125): rfc_obs_sig2
Others: Reserved
94
I/O Ports SWRU191C–April 2009–Revised January 2012
Submit Documentation Feedback
Copyright © 2009–2012, Texas Instruments Incorporated
