Interrupts

Table 2-8. Interrupt Polling Sequence

Interrupt Number Interrupt Name

0 RFERR

16 RF

8 DMA

1 ADC

9 T1

2 URX0

10 T2

3 URX1

11 T3

Polling sequence

↓

4 ENC

12 T4

5 ST

13 P0INT

6 P2INT

7 UTX0

14 UTX1

15 P1INT

17 WDT

SWRU191C–April 2009–Revised January 2012 8051 CPU

Submit Documentation Feedback
