RF Core Data Memory
Table 25-3. Access to FIFO Registers
Register Read Access Write Access
MCU MCU
RFD
Depends on command:
0x81 : Reset Rx FIFO: MCU*
0x82 : Deallocate Rx FIFO: MCU
0x83 : Retry Rx FIFO: MCU
0x84: Discard Rx FIFO: LLE
0x85: Commit Rx FIFO: LLE
0x91 : Reset Tx FIFO: MCU*
0x92 : Deallocate Tx FIFO: LLE
(1)
N/A
RFST (FIFO commands)
0x93 : Retry Tx FIFO: LLE
(1)
0x94: Discard Tx FIFO: MCU
0x95: Commit Tx FIFO: MCU
0xF1: Reset both fifos: MCU*
0xF2: Deallocate both fifos: none
0xF3: Retry both fifos: none
0xF4: Discard both fifos: none
0xF5: Commit both fifos: none
Both MCU
RFFDMA0
Both MCU
RFFDMA1
Both N/A
RFFSTATUS
Both MCU
RFFCFG
Both N/A
RFRXFLEN
Both MCU
RFRXFTHRS
N/A LLE
RFRXFWR
MCU N/A
RFRXFRD
Both LLE
RFRXFWP
Both MCU
RFRXFRP
Both LLE
RFRXFSWP
Both MCU
RFRXFSRP
Both N/A
RFTXFLEN
Both MCU
RFTXFTHRS
N/A MCU
RFTXFWR
LLE N/A
RFTXFRD
Both MCU
RFTXFWP
Both LLE
RFTXFRP
Both MCU
RFTXFSWP
Both LLE
RFTXFSRP
(1)
MCU if PRF_ADDR_ENTRYn.CONF.RETRY is 1
25.3.2 DMA
It is possible to use direct memory access (DMA) to move data between memory and the radio. See
Chapter 8 for a detailed description on how to set up and use DMA transfers.
There are two DMA triggers associated with the radio: the RADIO DMA triggers 0 and 1 (DMA triggers 19
and 11).
The radio DMA trigger source is selected in registers RFFDMA0 and RFFDMA1. See the register
descriptions in Section 25.12 for details.
