Chapter 9
SWRU191C–April 2009– Revised January 2012
Timer 1 (16-Bit Timer)
Timer 1 is an independent 16-bit timer which supports typical timer/counter functions such as input
capture, output compare, and PWM functions. The timer has five independent capture/compare channels.
The timer uses one I/O pin per channel. The timer is used for a wide range of control and measurement
applications, and the availability of up/down count mode with five channels allows, for example,
implementation of motor-control applications.
The features of Timer 1 are as follows:
• Five capture/compare channels
• Rising, falling, or any-edge input capture
• Set, clear or toggle output compare
• Free-running, modulo, or up/down counter operation
• Clock prescaler for divide by 1, 8, 32, or 128
• Interrupt request generated on each capture/compare and terminal count
• DMA trigger function
