www.ti.com
MMWAVEICBOOST
21
SWRU546C–October 2018–Revised April 2020
Submit Documentation Feedback
Copyright © 2018–2020, Texas Instruments Incorporated
mmWaveICBoost and Antenna Module
Table 7. J17 Connector Pinout
Pin Number Pin Description Pin Number Pin Description
1 5V 31 GND
2 5V 32 LVDS_3P
3 5V 33 GND
4 VPP_1.7V 34 LVDS_3M
5 GND 35 NC
6 NC 36 GND
7 3.3V 37 NC
8 NC 38 LVDS_2P
9 3.3V 39 NC
10 NC 40 LVDS_2M
11 PMIC_EN 41 NC
12 NC 42 GND
13 DP8 43 NC
14 NC 44 NC
15 DP9 45 NC
16 NC 46 NC
17 DP10 47 NC
18 GND 48 NC
19 DP11 49 NC
20 LVDS_VALIDP 50 NC
21 DP12 51 NC
22 LVDS_VALIDM 52 NC
23 DP13 53 NC
24 GND 54 NC
25 DP14 55 NC
26 NC 56 NC
27 DP15 57 NC
28 NC 58 NC
29 GND 59 NC
30 GND 60 NC
