mmWaveICBoost and Antenna Module
Figure 54. Modular mode setup
S1 switch setting for functional and flashing mode is shown in Table 18
Table 18. S1 config flashing and functional mode
s1.1 s1.2 s1.3 s1.4 s1.5 s1.6
Flashing On Off On On Off -
Functional Off Off On On Off -
