IWR6843AOPEVM (Deprecated)
www.ti.com
78
SWRU546COctober 2018Revised April 2020
Submit Documentation Feedback
Copyright © 2018–2020, Texas Instruments Incorporated
mmWaveICBoost and Antenna Module
6.8.2 Flashing the Board
1. Ensure the drivers have been successfully installed and COM ports enumerated.
2. Configure the SOP to flashing mode.
3. Run the UniFlash tool.
4. Press the reset switch to ensure that the board boots up in the right mode.
5. Enter the Enhanced COM Port in the UniFlash interface.
6. Load image to serial flash.
6.8.3 DCA1000
For data capture using the DCA1000, set up the board to mounted mode, having the SOP and UART
muxed set correctly. Continue as you would with the xWR6843ISK. For more information, see
Section 2.5.3.
6.9 REACH Compliance
In compliance with the Article 33 provision of the EU REACH regulation, this is to notify you that this EVM
includes component(s) containing at least one substance of very high concern (SVHC) above 0.1%. The
uses from Texas Instruments do not exceed 1 ton per year. The SVHC’s are:
Component
Manufacturer Component Type
Component Part
Number SVHC Substance
SVHC CAS (when
available)
Bivar LED SM0402GC
1,3,5-tris(oxiranylmethyl)-1,3,5-triazine-
2,4,6(1H,3H,5H)-trione
2451-62-9
7 TI E2E Community
Search the forums at e2e.ti.com. If you cannot find your answer, post your question to the community!
