mmWaveICBoost and Antenna Module
3.9 DCA1000EVM Mode
The setup for raw data capture using DCA1000EVM is shown in Figure 55
Figure 55. DCA1000EVM mode
S1 switch settings for this mode is shown in Table 19
Table 19. S1 Config for DCA1000EVM mode
S1.1 S1.2 S1.3 S1.4 S1.5 S1.6
DCA1000EVM
mode
OFF ON ON OFF OFF -
